Dimensions
Size comparison
IC-M510BBHX40E
| IC-M510BB | HX40E | Difference | |
|---|---|---|---|
| Height | 79 mm | 95 mm | −16 mm |
| Width | 216 mm | 52 mm | +164 mm |
| Depth | 113 mm | 33 mm | +80 mm |
| Weight | 890 g | 230 g | +660 g |
Drawn to the same scale from the official dimensions (front and side).
Why is IC-M510BB better than HX40E?
- Transmit power25 W vs 6 W4.2×
Why is HX40E better than IC-M510BB?
- Weight890 g vs 230 g3.9×
Specifications
Side by side
| Radio & range | ||
| Radio standards | Amateur VHF, Marine VHF | Amateur VHF, Marine VHF |
| Frequency ranges | 156.025 - 162 MHz | 156.025 - 163.275 MHz |
| Transmit power | 25 W | 6 W |
| Squelch | adjustable | adjustable |
| Power & battery | ||
| Battery capacity | — | 1,850 mAh |
| Battery voltage | 12 V | 7.4 V |
| Power source | Mains / 12 V vehicle | Rechargeable pack |
| USB-C charging | No | No |
| Battery level indicator | — | Yes |
| Design & durability | ||
| Weight | 890 g | 230 g |
| Width | 216 mm | 52 mm |
| Height | 79 mm | 95 mm |
| Depth | 113 mm | 33 mm |
| Protection rating | IPX7 | IPX7 |
| Water protection (IPx) | IPx7 | IPx7 |
| Display | Backlit display | Backlit display |
| Colours | Black | Black, Orange |
| Features | ||
| Channel scan | Yes | Yes |
| Dual watch | Yes | Yes |
| Emergency / SOS alarm | Yes | Yes |
| FM radio | — | Yes |
| Key lock | — | Yes |
| GPS | Yes | — |
| PC programmable | Yes | Yes |
| Connectivity | ||
| Headset / earpiece jack | Yes | Yes |
| Connectors | 8‑polige Mikrofonbuchse | 3,5mm Klinke |
| Radios in the base pack | — | 1 |
