Dimensions
Size comparison
HAM-10RT3S
| HAM-10 | RT3S | Difference | |
|---|---|---|---|
| Height | 175 mm | 61 mm | +114 mm |
| Width | 182 mm | 131 mm | +51 mm |
| Depth | 53 mm | 36 mm | +17 mm |
| Weight | 1,500 g | 258 g | +1,242 g |
Drawn to the same scale from the official dimensions (front and side).
Why is HAM-10 better than RT3S?
- Transmit power40 W vs 5 W8×
Why is RT3S better than HAM-10?
- Weight1,500 g vs 258 g5.8×
Specifications
Side by side
| Radio & range | ||
| Radio standards | Amateur | Amateur VHF, Amateur UHF |
| Licence | Amateur licence | Amateur licence |
| Dual band (VHF + UHF) | — | Yes |
| Frequency ranges | 28 - 29.7 MHz | 450 - 460 MHz; 150 - 160 MHz |
| Transmit power | 40 W | 5 W |
| Channels | — | 3,000 |
| CTCSS / DCS sub-tones | — | Yes |
| Squelch | automatic, adjustable | adjustable |
| Power & battery | ||
| Battery capacity | — | 2,000 mAh |
| Battery voltage | 13.8 V | 7.4 V |
| Power source | Mains / 12 V vehicle | Rechargeable pack |
| USB-C charging | No | No |
| Battery level indicator | — | Yes |
| Design & durability | ||
| Weight | 1,500 g | 258 g |
| Width | 182 mm | 131 mm |
| Height | 175 mm | 61 mm |
| Depth | 53 mm | 36 mm |
| Display | Backlit display | Backlit display |
| Colours | Black | Black |
| Features | ||
| VOX (hands-free) | — | Yes |
| VOX sensitivity levels | — | 10 |
| Channel scan | Yes | Yes |
| Dual watch | Yes | — |
| Emergency / SOS alarm | Yes | — |
| Key lock | Yes | Yes |
| Roger beep | Yes | — |
| Monitor button | — | Yes |
| PC programmable | — | Yes |
| Connectivity | ||
| Headset / earpiece jack | Yes | Yes |
| Connectors | 3,5mm Klinke, 4polige Mikrofonbuchse | 2,5 und 3,5 mm |
| Radios in the base pack | 1 | 1 |
